Retractable Awning

MODEL: HSUM1012

Our Retractable Awning features an all aluminum & stainless steel construction, and utilizes high-grade nylon components. The frame parts & fabrics can be exchanged for easy maintenance, cleaning & repair. The awning is available with a wide variety of fabrics and continuous length aluminum rib extrusions (1.3" dia) support the individual fabric panels. Modular twin posts allow for the creation of continuous runs of shade cover, virtually unlimited in length. Installed in your choice of Ground Insert, Deck Mount, or Free-standing bases. Available sizes: 8' D x 10', 12', 14', or 16' W | 10' D x 10', 12', 14', or 16' W

DIMENSIONS

Width: 144 in (365.8 cm)
Depth: 120 in (304.8 cm)
Height: 87 in (221.0 cm)
Weight: 193.0 lb (87.62 kg)






MORE DOWNLOADS: (Login required)
CSI Specification
DWG Drawing
SKETCH-UP Model
REVIT Model


Please Note: Downloads for CSI Spec, CAD files and models for SketchUp and Revit are in process for all products. Online quoting is now available for registered users.




MATERIAL OPTIONS

STANDARD ACRYLIC FABRIC (SUNBRELLA®) (PDF)

Pewter
Pewter
Titanium
Titanium
Bronze
Bronze
Gunmetal
Gunmetal
Ocean Blue
Tangerine
Lime Green
Designer White, Low Sheen
Slate Black
Slate Black, Low Sheen Sandtex
Textured Stone
Textured Stone, Low Sheen Sandtex
Frosted Pewter
Frosted Pewter, Smoothtex
Crinkle Black
Crinkle Black, Smoothtex
Crinkle White
Crinkle White, Smoothtex
Celeste Blue, Smoothtex
Absinthe Green, Smoothtex
Nutmeg, Sandtex
Nutmeg, Sandtex
Frosted Titanium
Frosted Titanium, Smoothtex
Ipe
Ipe
Envirowood Sand
Sand
Envirowood Grey
Grey
Envirowood
Walnut
Driftwood Weave
Strap-Tech
Strap-Tech (US-CB150-UC-10-AL)
Strap-Tech Backless
Strap-Tech Backless (US-CB151-UC-10-AL)
Perf-Tech
Perf-Tech (US-CB170-UC-10-AL)
Slot-Tech
Slot-Tech (US-CB160-UC-10-AL)
Shutter
Shutter (US-CB310-UC-10-AL)
Sonic Backless
Sonic Backless (US-CB321-UC-10-AL)
Sonic
Sonic (US-CB320-UC-10-AL)
Yellow
Sand
Red
Grey
Green
Brown
Blue
Black
