Trellis, 16' x 29' x 10.5' H

MODEL: ST05-ITZ-C15VO-16x29-10.5 - Trellis

A modern take on a traditional design, our 'Trellis' offers the versatility to enhance any outdoor space.  The core frame consists of a heavy-duty 4" x 4" aluminum columns and cross beams, professionally engineered to withstand the demands of an exterior commercial environment.  Accommodate a unique space with a custom trapezoidal frame with vertically oriented, overhanging 1.5" x 5.5" sealed Cedar purlins chamfered at each end to complete the design.  Also available are a selection of aluminum overhanging or underhanging purlins. The Trellis incorporates our proprietary Konnectr System to ensure that each design is as fluid as possible, while still meeting the requisite load and wind analysis. Custom engineered Konnectr Blocks and stainless steel countersunk hardware, ensure that each beam and column connection is seamless, strong and virtually undetectable. Built-in surface mount plates with decorative covers provide the finishing element. The frame has been designed to accept a variety of lighting, charging and heat options. Custom sizes are available.


DIMENSIONS

Width: 352 in (894.1 cm)
Depth: 189 in (480.1 cm)
Height: 125 in (317.5 cm)






Please Note: Downloads for CSI Spec, CAD files and models for SketchUp and Revit are in process for all products. Online quoting is now available for registered users.
