Overlapping Grand Pergola, 23' x 22' x 10.5' H

MODEL: ST12-OL-AW25V-23x22-10.5-10 - Grand Pergola

Imagination is the only limitation when it comes to designing a custom shade structure.  These overlapping Grand Pergolas are no exception.  Heavy-duty, all-aluminum 6” x 6” columns and cross beams are place in a ‘T’ configuration to form two overlapping Grand Pergolas.  Our professionally engineered proprietary Konnectr System ensures that this design is as fluid as possible, while still meeting the requisite load and wind analysis.  Contrasting vertically oriented 2” x 5” AlumiWOOD roof purlins cascading down into side privacy panels complete this impressive structure.  Originally conceived by Site/C Landscape Architecture, this dramatic structure is certain to leave a lasting impression.


DIMENSIONS

Width: 264 in (670.6 cm)
Depth: 276 in (701.0 cm)
Height: 126 in (320.0 cm)






Please Note: Downloads for CSI Spec, CAD files and models for SketchUp and Revit are in process for all products. Online quoting is now available for registered users.




ROOF OPTIONS

PRIVACY PANEL OPTIONS

MATERIAL OPTIONS

METAL FINISHES - ALUMINUM FRAME / SLATS / PANELS (PDF)

AlumiWOOD FINISHES – SUBLIMATED ALUMINUM SLATS / PRIVACY PANELS (PDF)

EXTERIOR WOOD SPECIES - ROOF SLATS / PRIVACY PANELS
